Sheet Perforator TC 1530 C

Produce remittance stubs, coupons, convenience checks, and tear-out workbook pages in-line with your Canon varioPRINT iX-series sheetfed inkjet color press.

Choose from dynamic perforation models with two or four vertical perforation wheels, and zero (C0, for very simple remittance stub-like perforation needs), one (C1), or two (C2) horizontal cylinders, to best match your needs. The TC 1530 C series features an optional two horizontal perforation blades per shaft, cutting in half the minimum horizontal perforation repeat available at a given speed.

The basic system is field upgradable (hardware and software) to add both horizontal and vertical perforation tools. Your investment decision today is secured to support more complex applications of tomorrow. A 2D Datamatrix on each page triggers one of up to 89 pre-programmed perforation patterns page-by-page within your job.

Specifications
Speed max.	160 ppm A4 size ≈ 156 ppm letter size
Paper weight	18.5# bond – 7.5 pt
Form width	178 – 363 mm ≈ 7” – 14.3”
Form length	178 – 520 mm ≈ 7“ – 20.5”
Cross perf. width	356 mm max, 14” max
Cross perf. length	500 mm max, 19.7" max
Cross perf repeat minimums, 1 cylinder	1 blade = 5.5” min.; 2 blades = 2.75” min.
Cross perf repeat minimums, 2 cylinders	1 blade: 70 mm (2.75”); 2 blades: 35 mm (1.375”); (2 perfs may be infinitely close, but the next pair must be at least 2.75” or 5.5” away)
Vertical perf. distance	50 mm (2”) minimum; 6 mm (0.25") minimum with second shaft
Perf. specification	7 to 50 TPI (standard TPI is 15)
