• Sitma 960 High-Speed wrapping

    High-Speed Wrapping



    Bundle Packaging System

    Sitma 960

Stack_5x50_3D_001_Web-1600x950_crop

Sitma 960 represents the pinnacle of industrial bundle wrapping technology, combining high-speed performance with versatile and efficient wrapping capabilities.

Key Features


  • Continuous Motion Sealing technology wraps bundles without stopping

  • Ability to handle variability without operator intervention

  • speeds up to 50 bundles per minute

Tecnau logo frame

icon-quotes-gray

We no longer have the ‘have-the-job-but-can’t-get-it-done-in-time’ issue. Lead times are 30–50% less.


Brett Keene, CEO, Suttle-Straus

Read the Case Study

Designed for operations that demand the utmost in productivity and protection, these machines can handle the most challenging wrapping tasks with ease.


Sitma 960 is unique in its ability to wrap bundles on the fly, without stopping them as they pass through the sleeve wrapping station. This Continuous Motion Sealing technology ensures higher output and superior bundle handling, with speeds of up to 50 bundles per minute.

Both models—Sitma 960-H and Sitma 960H-961—offer the flexibility to sleeve-wrap or shrink-wrap bundles using a Sitma tunnel. The machines can handle variable sizes and thicknesses without operator intervention, making them adaptable to a wide range of packaging needs.

The 960 series incorporates a film buffer system that maintains a reservoir of film, draping it over incoming bundles without resistance. This ensures every bundle, no matter how small, is stable with a perfect seal. The film saver module further enhances efficiency by backing the film into the bundle during sealing, resulting in a tighter wrap at a lower material consumption.

Sitma 960 Bundle Packaging Machine
Sitma 960 Bundle Packaging Machine
Sitma 960 Bundle Packaging Machine

Technical Specifications


Specifications
Speed Up to 50 packages/min
Bundle width 960-H: 200 - 500 mm / 7.8” - 19.7”; 960H-961: 200 - 300 mm / 7.8” - 11.8”
Bundle length 960-H: 200 - 500 mm / 7.8” - 19.7”; 960H-961: 210 - 450 mm / 8.2” - 17.7”
Bundle height 960-H: 10 - 400 mm / 0.4” - 15.7”; 960H-961: 10 - 400 mm / 0.4” - 15.7”

Sitma 960 Model Options


Sitma 960-H

This solution is designed for ultimate versatility and efficiency, featuring an AC frequency inverter that keeps bundles square during operation. The machine offers simplified setup via  an LCD display with diagnostics, a “transport” mode for non-film running and an optional static eliminator.

Sitma 960H-961

The 960H-961 solution goes further by providing complete protection with side sealers that wrap all four sides of the bundle, ensuring longer product life. It can handle bundles up to 300 mm in height with continuous side sealing, and bundles over 300 mm can be sleeve-wrapped in conjunction with the side sealing station. The machine also features a recycling power system that evacuates film scrap into a collection bin.
